1.
Power button
|
8.
HDMI 1.4b
|
|
2.
Card reader *
|
9.
VGA
|
|
3.
Microphone (3.5mm)
|
10.
Ethernet (RJ-45)
|
|
4.
Headphone / microphone combo jack (3.5mm)
|
11.
2x USB 2.0
|
|
5.
USB-C 3.2 Gen 1 (support data transfer and 5V@3A charging)
|
12.
2x USB 3.2 Gen 1
|
|
6.
2x USB 3.2 Gen 1
|
13.
Power connector
|
|
7.
Line-out (3.5mm)
|
| Processor |
Intel Core i5-12400, 6C (6P + 0E) / 12T, P-core 2.5 / 4.4GHz, 18MB
|
| Graphics |
Integrated Intel UHD Graphics 730
|
| Chipset |
Intel B660
|
| Memory |
1x 4GB UDIMM DDR4-3200
|
| Memory Slots |
Two DDR4 UDIMM slots, dual-channel capable
|
| Max Memory |
Up to 32GB DDR4-3200
|
| Storage |
512GB SSD M.2 2280 PCIe 3.0×4 NVMe
|
| Optane Memory |
None
|
| Storage Support |
Up to two drives, 1x 3.5″ HDD + 1x M.2 SSD• 3.5″ HDD up to 2TB• M.2 SSD up to 1TB
|
| Card Reader |
7-in-1 Card Reader
|
| Optical |
None
|
| Audio Chip |
High Definition (HD) Audio, Realtek ALC623-CG codec
|
| Power Supply |
260W 85%
|
| DESIGN | |
| Keyboard |
USB Calliope Keyboard, Black, English
|
| Mouse |
USB Calliope Mouse, Black
|
| Expansion Slots |
Two M.2 slots (one for WLAN, one for SSD)
|
| Case Color |
Mineral Grey
|
| System Fan |
None
|
| Form Factor |
SFF (7.4L)
|
| Dimensions (WxDxH) |
100 x 303.5 x 274.8 mm (3.9 x 11.94 x 10.8 inches)
|
| Weight |
6.25 kg (13.8 lbs)
|
| CONNECTIVITY | |
| Ethernet |
Integrated 100/1000M
|
| WLAN + Bluetooth |
11ax, 2×2 + BT5.2
|
| Front Ports |
|
| Rear Ports |
|
| SECURITY & PRIVACY | |
| Security Chip |
Firmware TPM 2.0 integrated in chipset
|
| SERVICE | |
| Base Warranty |
1-year, Depot
|
| Included Upgrade |
3Y Onsite -Idea DT (ESS) (5WS0X58218)
|
| CERTIFICATIONS | |
| Green Certifications |
|
| SOFTWARE | |
| Operating System |
Windows 11 Home 64, Traditional Chinese / Simplified Chinese / English
|
| Bundled Software |
None
|
